Full Range Of Different Types Door Frames For Selection

Dongyang City Plastics Co.,Ltd is one of the most reliable manufacturers and suppliers of full range of different types door frames for selection in China. Welcome to wholesale high quality customized products at low price from our factory. Contact us for cheap products and free sample.

Basic Info.

WPC Door Frame types

Type A door frame cover

Type A

Structure: Reinforced, heavy-duty profile with an integrated door stop and pre-cut grooves for foam tape/rubber gaskets.

Features: Thicker cross-section (37–41mm) with extra support ribs; delivers superior sound insulation, airtight sealing, and structural stability.



Ordinary Door Frame

Ordinary

Structure: Basic, modular extruded profile without an integrated door stop; it's a "universal-fit" system that works with most standard wall thicknesses.

Features: Simple hollow-core design for light weight and cost efficiency; requires separate door stop strips and gaskets to be installed on-site.



Type B door frame cover

Type B

Structure: Slim, plug-in modular profile designed for quick assembly. The main and jamb parts fit together without complex machining.

Features: Uniform 31mm thickness; lightweight, easy to cut on-site, and highly cost-effective for mass production.







Type E Door Frame

Type E

Structure: Specialized, custom profile engineered exclusively for matching specific door slab sizes .

Features: Fixed dimensions that only work with compatible door slabs; optimized for specific door thicknesses and hardware setups.

1. Ordinary Door Frame

Best suited for:

Budget residential projects and bulk housing developments

Simple interior doors with standard wall thicknesses

Projects where the door stop will be installed on-site with separate accessories

Cost-sensitive commercial renovations

2. Type A Door Frame

Best suited for:

Mid-to-high-end residential homes and hotel guest rooms

Bathrooms, kitchens, and humid areas (due to integrated sealing)

Projects requiring good sound insulation and airtight performance

Permanent installations where long-term stability is a priority

3. Type B Door Frame

Best suited for:

Fast-track construction projects and apartment blocks

Rental properties and student housing (where quick, low-cost installation is key)

Standardized interior doors with uniform wall thicknesses

Large-volume orders requiring easy on-site cutting and assembly

4. Type E Door Frame

Best suited for:

Standardized production lines with pre-matched door slabs (e.g., X61/X91 sizes)

Custom door systems requiring precise, factory-fit compatibility

Projects where door and frame dimensions are pre-engineered for seamless assembly
